Home / Products & Services / Horizontal spiral/ screen filter centrifuge

Horizontal spiral/ screen filter centrifuge OEM

Huading horizontal spiral/screen filter centrifuge is a continuous operation, spiral unloading filter centrifuge designed for processing liquid-solid two-phase suspensions. Its core function is to achieve efficient solid-liquid separation through centrifugal force. It is suitable for materials with a solid phase particle size range of 0.05-10mm, especially for 0.3-2mm particles [1][3]. This equipment is widely used in chemical, food, chemical fiber, pharmaceutical, mining and environmental protection industries, such as separation of sodium metaborate, adipic acid, mirabilite, polyvinyl chloride, etc.
Contact Us Get a quote

Horizontal spiral/ screen filter centrifuge Manufacturers

Considerations for Rotor Material Selection

Selecting the appropriate material for screw pump rotors involves considering several factors:


  • Feeding and separation

    The suspension enters the high-speed rotating drum cavity through the feed pipe. Under the action of centrifugal force, the liquid phase is discharged through the filter pores, and the solid phase is intercepted to form a filter residue layer [1][3].

  • Solid phase propulsion

    There is a speed difference between the spiral blade and the drum (usually the speed difference ratio is 2-25r/min). The centrifugal force and spiral thrust are used to continuously push the solid phase from the small end of the drum to the large end, while turning the filter residue to enhance the dehydration effect.

  • Unloading and continuous operation

    The dehydrated solid phase is discharged from the large end slag discharge port. The whole process does not require shutdown, and continuous feeding, dehydration, washing and unloading are achieved.

  • Material and structure

     The drum, spiral and other key components are made of corrosion-resistant stainless steel or titanium alloy, and the filter thickness is up to 0.5mm (some models can be made of Hastelloy C276), which significantly extends the service life.

  • Intelligent control

     Equipped with variable frequency speed regulator and PLC control system, it realizes stepless speed regulation and differential adaptive compensation, and supports fully automatic operation.

  • Safety protection

     Integrated speed detection, over-vibration protection, motor overload protection and spiral zero differential protection to ensure safe operation.

Product Parameter

Comparison Criteria Huading LWL Series Plate & Frame Filter Press Piston Discharge Centrifuge
Operation Mode Continuous full-automatic Intermittent semi-automatic Continuous full-automatic
Processing Capacity Up to 30 m³/h Low (manual intervention required) Medium (frequent shutdown for discharge)
Energy Efficiency Energy consumption per unit output: 1/6.5 of knife centrifuges High (requires high-pressure pumps) Relatively high (periodic start-stop)
Applicable Materials 0.05-10mm particles, high-viscosity suspensions Prone to clogging, unsuitable for fine particles Requires uniform particle size
Maintenance Cost Fewer wearing parts, long-lasting lubrication system Frequent cloth replacement, high labor cost Rapid mechanical component wear
Automation Level Integrated PLC & VFD control, supports remote monitoring Relies on manual operation Limited automation



Application scenarios and case analysis
Chemical industry:
Adipic acid separation: Efficient treatment of high-concentration suspensions, solid phase recovery rate ≥ 95%, filter cake moisture content less than 5%.
Ammonium sulfate purification: Improved equipment is used for industrial waste liquid salt extraction, with an average daily processing capacity of 30 tons, reducing waste residue treatment costs by more than 30%.
Food industry:
Starch dehydration: Used for starch washing and grading in light industry, the starch moisture content after dehydration is ≤40%, significantly improving drying efficiency.

Product Category:
Horizontal spiral/ screen filter centrifuge
Product:

    information to be updated

Company
Yixing Huading Machinery Co.,Ltd.
Yixing Huading Machinery Co.,Ltd. (Huading Separator) was established in 1954. It is reputable China Horizontal spiral/ screen filter centrifuge Manufacturers and OEM Horizontal spiral/ screen filter centrifuge Factory of specialized products and engineering solutions in China, relying on its own key technologies for clarification, purification, and concentration.
The equipment (disc centrifuge, decanter centrifuge), systems, and services provided by Huading are specifically designed to help customers improve the performance of optimized processes. The solutions provided by Huading can help customers solve separation and filtration problems in the production process.
Huading's disc centrifuges and decanter centrifuges serve the industries of biomedicine, beverages, plant extraction, dairy products, the oil industry, chemical energy, water treatment, and other industries. The capacity of disc centrifuges and decanter centrifuges ranges from experimental 500L/H to industrial 90T/H, with a total of more than 100 standard models. China Ting's organization works closely with customers to help them stay ahead of the industry.
Efficient, powerful, and reliable. For more than 50 years, China Ting separators have always played the role of defender in the field of centrifugal separation technology. Therefore, it can be said that China Ting's development process has not only brought about its responsibility to customers, but also created the company's vision.
