Automatic horizontal scraper centrifuge OEM

Huading fully automatic horizontal scraper centrifuge is a high-efficiency solid-liquid separation equipment, designed for chemical, pharmaceutical, food, and other industries, with full automatic cycle operation capability. The equipment realizes the automation of feeding, separation, washing, dehydration, unloading, and other processes through PLC program control, and supports free switching between manual and automatic modes. Its core design takes into account both safety and production efficiency and is especially suitable for the treatment of flammable, explosive, or toxic materials.
Contact Us Get a quote

Automatic horizontal scraper centrifuge Manufacturers

Working principle


  • Fully automatic cycle process

    The main engine automatically increases speed after starting, and the inert gas (such as nitrogen) is replaced in the machine. After reaching the preset speed, the feed valve opens, and the material layer thickness is monitored in real time by the detector. The suspension is separated under the action of centrifugal force, the liquid phase is discharged through the filter cloth, the solid phase forms a filter cake, and finally unloaded through the scraper.


  • Siphon technology enhancement

    Some models (such as GKH type) combine the siphon principle, optimize the filtration speed by adjusting the siphon tube depth, and are equipped with a backwash device to achieve filter cloth regeneration.



Technical features


  • Intelligent control

    PLC+touch screen human-machine interface, integrated electrical-hydraulic actuator, support remote monitoring and parameter setting.


  • Safety protection

    Multiple protection systems include over-vibration detection, cover opening interlock, nitrogen protection, motor overload protection, etc., to ensure the safe operation of the equipment under high-quality conditions.


  • Sealing design

    Fully enclosed explosion-proof structure, with dovetail door cover and multiple seals (lip seal, labyrinth seal, etc.), meeting GMP standards and explosion-proof requirements.


  • Vibration reduction system

    Integrated floating platform and imported damping shock absorber, no fixed foundation required, reducing vibration interference to the environment.


  • Efficient energy saving

    Variable frequency speed regulation and energy feedback braking technology to achieve stepless speed regulation and low energy consumption operation


Application scenarios and industry Adaptability

Applicable industries

  • chemical industry

    It is used for solid-liquid separation of raw materials, dyes, polymers, etc.


  • Pharmaceutical industry

    GMP compliant for aseptic production and toxic substance handling


  • food

    Dehydration and purification of starches, amino acids, condiments, etc.


  • environmental protection

    Sewage treatment, solid waste recycling.



Material adaptability


  • Particle range

    0.05-1mm organic/inorganic particles.


  • Special scenes

    Supports the separation of protein-containing and colloidal substances and requires a degreasing device.



Configuration items Configuration details
Control methods PLC control; Touchscreen made; Support fully automatic/manual switching
Discharge mode Unloading with an open chute or integrated screw conveyor; Anti-clogging design
Security protection nitrogen protection; Over-vibration detection; Layer controller; Electromechanical interlocking
Optional add-ons CIP (Cleaning-In-Place) system; hydraulic locking device; Steel platform.
